Leader 1500V IP68 TUV Certification UV Resistant MC4 Solar Connector for Panels Cables
USD 0,38 – 0,48
/ pair
El precio varía según cantidad y especificaciones
| Cant. mín. | 500 pair |
| Categoría | Electronics |
18
Años
98%
Tasa de respuesta
24h
Tiempo de respuesta
Descripción del producto
No hay descripción disponible. Por favor envíe una consulta para más información.
Especificaciones técnicas
| Model NO. | PV-BN101A |
| Type | Socket Terminals |
| Material | Copper |
| Application | Conduct Electricity, Transmission of Electrical Signals, Solar Power System |
| Character | High Temperature Resistance |
| Species | Terminal |
| Production Process | Welding |
| Shape | Round |
| Interface Type | DC/DC |
| Certification | CE, TUV, Retie |
| Brand | Leader |
| Insulation Material | PPO |
| Rated Voltage | TUV 1500 DC/ UL 600V DC |
| Test Voltage | 6kv(50Hz, 1min) |
| Contact Material | Copper, Tin Plated |
| Contact Resistance | Less Than 0.5 M Ohm |
| Degree of Protection | IP68 |
| Pollution Degree | 2 |
| Protection Class | Class II |
| Flame Calss | UL94-V0 |
| Ambient Temperature Range | -40 ~ + 90. |
| Transport Package | 500pair/Carton |
| Specification | one pair |
| Trademark | LEADER |
| Origin | China Mainland |
| HS Code | 8536900000 |
